概述Ultima2 系列3分频中置声道扬声器
频率响应-3 dB from 60 Hz to 45 kHz ±0.5 dB from 65 Hz to 18 kHz ±1.0 dB from 65 Hz to 20 kHz
低频响应-10 dB at 36 Hz -6 dB at 49 Hz -3 dB at 60 Hz
灵敏度 (2.83V @ 1m)89 dB SPL with 2.83 V @ 1m (4 pi anechoic)
系统阻抗6 ohms (nominal) 3.6 ohms (minimum @ 90 Hz)
分频点 (Hz)Three-way, high-order acoustic response @ 235 Hz and 2 kHz
高音单元1" (2.5 cm) beryllium tweeter
中音单元5 ¼" (13.3 cm) titanium cone midrange
低音单元Two 8" (20 cm) titanium cone woofers
外形尺寸Dimensions (H x W x D): 14.7" x 25.5" x 14" (37.3 cm x 64.8 cm x 35.6 cm)
重量Weight: 62 lb (28.2 kg) / Shipping weight: 74.5 lb (33.8 kg)
外饰面Piano black or mahogany finish
可选配件Optional Floor Pedestal for Voice2 • Adds 24.2" (61.4 cm) to Voice2 height • Piano black finish only
